HYBRID-WHEEL DRIVE HEAVY-DUTY POWER WHEELCHAIRS

Heavy-Duty Power. Zero Compromise.

Get stability, speed and maneuverability with the industry’s only heavy-duty HWD power wheelchair. Strength meets sophistication in the Alltrack R3-HD, a true Hybrid-Wheel Drive (HWD) power wheelchair that doesn’t force you to choose between performance and agility. Designed for users up to 400 lb, it offers the rugged stability, comfort, and confidence of a rear-wheel drive—paired with a compact footprint and tight turning radius for everyday indoor maneuverability. With upgraded heavy-duty components and suspension tuned specifically for higher weight capacity, the R3-HD empowers users to go further, with no trade-offs and no limits.

HIGHLIGHTS

True Hybrid-Wheel Drive (HWD) design
The industry’s only Heavy-Duty HWD power wheelchair.
Outdoor performance and driving feel of rear-wheel drive with compact mid-wheel agility
Heavy-Duty Design engineered for users up to 400 lb (181 kg), without compromising comfort, agility, or performance.
Ultra-Compact 21.75” (550 mm) turning radius for excellent indoor maneuverability
Seat-to-Floor Height as low as 15.5”, supporting easier transfers and better access to daily environments.

Click here to watch the video

Brand	AMYLIOR
Configuration	Hybrid-wheel drive – Heavy-duty (Alltrack R3-HD Hybrid)
HCPCS Codes	K0850/K0858/K0862
Suspension system	Patented Dual-Action Suspension: Fully independent 6-wheel interactive suspension with vertical shock absorption
Ground clearance¹	3.5” (90 mm) with 14” (355 mm) drive wheels, 2.875” (75 mm) with 12.5” (320 mm) drive wheels
Base width²	25.375” (645 mm) with GP 24 batteries
Base length²	35.875” (910 mm)
Base turning radius	21.75” (550 mm)
Weight capacity	0-400 lb (0-180 kg)
4-Pole motor options	6.5 mph (10 km/h)
Transit option (Unoccupied)	4-point tie-down attachment points compliant with ISO 7176-19
Battery types	Two 12 V, deep cycle Gel cell Group 22NF (50 Ah) or Group 24 (70 Ah)
Battery charger	8 A, off board
Electronics	Rnet (expandable 120 A)
Assistive driving package	Available with Smart-Track technology
Specialty controls	Compatible with Mo-Vis, ASL, Switch-It and Stealth as well as other current systems
Seat width range	Adjustable from 14” to 26” (355 mm to 660 mm) wide
Power seating option and HCPCS codes³	Standard or HD weight capacity for Power Tilt (E1002), Power Recline with Mechanical Shear Reduction (MSR) (E1004), Combination Power Tilt and Recline with MSR (E1007), Center Mount Elevating & Articulating Foot Platform (E1012), Independent Power Elevating & Articulating Legrests (E1010), Alta Power Seat Elevation (E2298)
Seat to floor height range (HD Tilt)	15.5” to 19.5” (395 mm to 495 mm)
Seat to floor height range (HD Seat Elevate)	17” to 20″ (430 mm to 510 mm)
Seat to floor height range (Tilt AND HD Seat Elevate)	18.5” or 19.5” (470 mm or 495 mm)
Component weights⁴	Standard base width 25.375” (645 mm): 132 lb (59 kg) Batteries: Group 24: 2 x 54 lb (24.5 kg)
Drive wheel diameter	12.5” or 14” (320 mm or 355 mm)
Caster wheel diameter	8” or 9” (205 mm or 230 mm)

1. Subject to variances depending on configuration and manufacturing tolerances.
2. Dimensions listed are for power base only.
3. Custom specialized power seating options available.
4. Contact Customer Service for additional weight information.

SIGNATURE – Tailored Positioning Solutions

Why Signature?

Our all-new Signature power positioning system has been completely re-imagined, delivering a new modern aesthetic, enhanced adjustability and all the durability and reliability Amylior is known for. Available on every Alltrack model, Signature boasts industry leading modularity and the capability to provide Tailored Solutions for even the most complex positioning needs.

Tailored for the user	Highly modular with adjustments to meet the unique needs of virtually any user. Easier and faster adjustments—without compromising structural integrity.
Durability meets design	High-quality, durable construction designed to maintain structural integrity. Improved aesthetics with a sleek, modern look. Lighter weight for easier handling and transport, yet stronger than ever.
Adjustable and adaptable	Offering adaptable capabilities and high weight capacities up to 550 lb. Minimum seat-to-floor heights remain unchanged and start at 15.5″ on Standard and HD models, and as low as 17″ on VHD model Compact and narrow base options are perfect for pediatric users. Designed to evolve and grow with the user. Simplified, faster and easier adjustment.
Efficiency and reliability	Improved efficiency in production and delivery for quicker lead times and order accuracy. Thoughtfully designed for seamless integration of a wide range of electronic, seating and positioning accessories, making sure both users and technicians experience ease and reliability. Signature is built with the future in mind, with a single manufacturer for your seating, power mobility, and power positioning needs.
Exclusively Amylior	All of our products are engineered and assembled in North America. One manufacturer that can handle all your power mobility needs from simple to complex, pediatric to bariatric.
Custom Solutions	Built with versatility at its core, Signature features a modular design that supports a wide range of custom seating and positioning configurations—including specialized cushions, backrests, and lateral supports. Offers full integration of advanced power positioning solutions including lateral tilt, latitude systems, power headrests, power swing-away mounts, and vertical or flip-up foot platforms — with configurations designed to meet a wide variety of user needs. Extensive adjustability in height, width, depth, and length ensures a truly tailored fit, supporting complex clinical needs while promoting posture, comfort, and long-term mobility.
